JINKO SOLAR 470W PANEL – JKM470M
R1,420.00
The Jinko 470W Tiger Mono Facial solar panel is a 470W monocrystalline module with 156 cells from Jinko Solar, one of the world’s leading manufacturers of the photovoltaic industry. It’s TR technology and half-cell aims to eliminate the cell gap to increase module efficiency (mono-facial up to 21.6%). Jinko solar panels come with a 12-year product warranty and a 25-year linear power warranty.
Product Specifications:
- Cell Type: P type Mono-crystalline
- of cells: 156 (2×78)
- Dimensions: 2182×1029×40mm (85.91×40.51×1.57 inch)
- Nominal Max. Power (Pmax): 470w
- Operating Voltage (Vmp): 43.28V
- Operating Current (Imp): 10.86A
- Open Circuit Voltage (Voc): 52.14V
- Short Circuit Current (Isc): 11.68A
- Module Efficiency up to: 20.93%
Out of stock
Description
The Jinko 470W Tiger Mono Facial solar panel is a 470W monocrystalline module with 156 cells from Jinko Solar, one of the world’s leading manufacturers of the photovoltaic industry. It’s TR technology and half-cell aims to eliminate the cell gap to increase module efficiency (mono-facial up to 21.6%). Jinko solar panels come with a 12-year product warranty and a 25-year linear power warranty.
Product Specifications:
- Cell Type: P type Mono-crystalline
- of cells: 156 (2×78)
- Dimensions: 2182×1029×40mm (85.91×40.51×1.57 inch)
- Nominal Max. Power (Pmax): 470w
- Operating Voltage (Vmp): 43.28V
- Operating Current (Imp): 10.86A
- Open Circuit Voltage (Voc): 52.14V
- Short Circuit Current (Isc): 11.68A
- Module Efficiency up to: 20.93%
